| Supply Power | 220 VAC; 380VAC (50/60Hz) | |
Explosion Protected | ATEX Exd IIC T5 / T6; Non Ex | |
Degree of protection | IP67 / IP68 | |
Ambient Temperature | -40 to +80℃ | |
Input/output Signal | Control type： 4 –20 mA / 0 –10(5)V | |
On/off type： ON/OFF (Dry contact switch) | ||
Alarm Way | 3 – 6 Ways | |
Electrical connection | 2 – M32/20 x1.5 | |
Full Stroke time | 7 – 300 Seconds | |
Rotary output Torque | 180-250000 Nm | |
Linear output Thrust | 20-200KN (On request) | |
Rotary Stroke | 90°/ Multi-turn | |
Linear Stroke | 40/65/135 mm (On request) | |
<
>
