| Supply power | 24 VDC ; 24/110/220/380 VAC(50/60Hz) | |
| Explosion protection | Non-Ex | |
| Degree of protection | IP65/66/67 | |
| Ambient temperature | -40 to +80℃ | |
| Input/Output signal | Control mode：4 –20 mA / 0 –10(5)V | |
| On/off mode: Dry contact switch | ||
| Communication mode | Mod-bus / M-bus / NB / LOAR / 4G | |
| Alarm way | 2 – 4 Ways | |
| Power fail-safe reset position | FL(Fail lock/hoid） | |
| Electrical connection | 2 – M20x1.5 (Standard) | |
| Full stroke time | 7 – 300 seconds | |
| Rotary output torque | 50 – 600 Nm | |
| Linear output thrust | 2 -12 KN | |
| Rotary stroke | 90° / multi-turn | |
| Linear stroke | 20/40/65mm | |
<
>
