| Supply power | 24 VDC; 24/110/220/380 VAC (50/60Hz) | ||||||||
Explosion protection | ATEX IEC Exd IIC T5 / T6；non-Ex | ||||||||
Degree of protection | IP66; IP67; IP68 | ||||||||
Ambient temperature | -40 to +80℃ | ||||||||
| Input/Output signal | Control mode：4 –20 mA / 0 –10(5)V | ||||||||
| On/off mode: Dry contact switch | |||||||||
Communication mode | Mod-bus / M-bus / NB / LOAR / 4G | ||||||||
Alarm way | 3 – 6 Ways | ||||||||
Power fail-safe reset position | FL/FC/FO/FS | ||||||||
Electrical connection | 2 – M20x1.5 (Standard) | ||||||||
| Full stroke time | 7 – 300 seconds | ||||||||
Rotary output torque | 50 – 1200Nm | ||||||||
Linear output thrust | 2 – 48 KN | ||||||||
| Rotary stroke | 90° /multi-turn | ||||||||
Linear stroke | 20/40/65/135mm... | ||||||||
<
>
